Reconditioned Fiat Engine

Reconditioned Fiat Engines: from the 8140.43S of the early Ducato to the F1AGL411 of post-2014 generations

Between 2003 and 2024, the Fiat range went through several major technical changes that make identifying the correct engine particularly tricky. The engine code — not the engine capacity alone — is the essential starting point here. A 2.3 Multijet can conceal a F1AGL411C, a F1AGL411D, a F1AGL411M or even a F1AE0481D depending on the generation and emissions standard: these codes are not mechanically interchangeable. The same applies to the 1.3 Multijet, fitted to the 500, the Doblo, the Panda and the Punto under the codes 250A1000, 250A2000 or 199B1000 depending on the power output and the Euro standard applied.

Ducato and Talento: two architectures, very different codes

The Ducato accounts for the bulk of the range, with engines spanning from the older 2.8 JTD (8140.43S) to the 2.3 and 3.0 Multijet units found in more recent fleets. The Talento, meanwhile, shares its mechanical platform with the Trafic III: its codes R9MMA, R9MMB, R9MMC, R9MMG, R9MMH denote variants of the Renault 1.6 twin-turbo (R9M), with differences in mapping and torque outputs. Confusing an R9M with an F1AGL411 simply because both are 1.6 or 2.0 diesels would be a costly misidentification.

Petrol, older diesels and Multijet: a quick reference guide

On the petrol side, the 500, the Panda and the Punto are fitted with the 1.2 8v (176A9000 / 199A9000), the 1.4 8v (330A1000) or the 1.4 16v, as well as the more recent 1.0 FireFly. These petrol units are available on an exchange basis as a reconditioned bare engine. For older-generation diesels — XUD9UTF, DW10UTED4, 1.9 D — found notably in the Scudo, part references (46349131, 46348913, 55282151) provide an exact match where the commercial name alone is not sufficient. Whatever the engine type, checking the engine code stamped on the block before placing any order remains the most reliable way to avoid a compatibility issue.
